Wharfedale T-SUB-AX Series 15" active subwoofer with 3" voice coil 700W continuous
Wharfedale T-SUB-AX Series 15" active subwoofer with 3" voice coil 700W continuous
SKU: SKU: TSUBAX15B
Description
Description
Wharfedale Pro 15" Sub 700 Watts RMS
The TSUBAX15B – is all-new 700w Continuous, 1400w Peak 15” active subwoofer. The internal Class D amplifier delivers huge output power into the custom quad-layer 15” Wharfedale Pro LF driver to produce extreme subs and low end pressure into any system. Built for big bass, the plywood constructed cabinet is rock solid and is protected in durable Rhino Rock paint. You’ll not only ‘feel’ the TSubAX15B, but you will also see it! A new illumated WP logo badge subtly glows and adds to the overall on-stage “power” of the new T-Sub. TSubAX15B is the perfect companion for a Typhon or a Titan active loudspeaker. It also has 75% more power than the current TitanSubA15 MKII.
Specification
Specification
- Sensitivity @ 1W / 1m): 97dB
- Frequency Response (+/-3dB): 45Hz-200Hz
- Maximum SPL (peak@1m): 129dB
- Impedance: 4Ω
- Low-Frequency Power Amplifier (Class D): 700w Continuous / 1400w Peak
- Crossover Frequency: LPF 80-200Hz (adjustable)
- Input Impedance: 47KΩ Balanced
- Maximum Input Level: 5V
- Input Sensitivity: -10dB
- Input Connectors: Female XLR
- Line Output Connector: Male XLR
- Phase Switch Selection: 0° / 180°
- Enclosure Material: 15mm Plywood
- Colour: Black
- Grille: 1.5mm steel
- Pole Mount(Top): 35mm
- Product Dimensions:
- Height: 591mm
- Width: 454mm
- Depth: 523.9mm
-
Weight Net Weight (kg / lbs) 25.7 kg / 56.5lbs Gross Weight (kg / lbs) 29.5 kg / 64.9lbs
