Electrovoice EV ZXA1 8" 2-way powered speaker

Electrovoice EV ZXA1 8" 2-way powered speaker

SKU: ZXA1

$1,099.00
$1,486.10 $1,099.00
Sale Sold out
Taxes included. Shipping calculated at checkout.

Low Stock – Call for Availability

Description

The Electro-Voice ZXA1 is powered by an 800 watt amplifier module derived from EV’s world-tour-class Tour Grade series amplifiers with audio quality and reliability proven at the very highest levels.

  • Integrated 800 watt power amplifier
  • Bi-amplified design with transducer protection
  • EV8L 8” high-output LF transducer
  • DH2005 1” exit true compression driver
  • 90° x 50° coverage pattern
  • Rotatable horn design
  • 126 dB maximum SPL
  • Selectable high-pass filter for use with subwoofers
  • Line and microphone inputs
  • Integral monitor angle on enclosure
  • Built-in pole mount
  • Lightweight (< 20 lbs) with integral handle for easy carrying

Buy from our range of DJ Equipment and DJ Speakers online.

Specification

Amplifier Power 800Watts (RMS)
Available Color Black
Coverage (Nominal -6 dB) H 90° (Rotatable)

Coverage (Nominal -6 dB) V 50° (Rotatable)
Crossover Frequency 1800Hz
Depth 10.39" (264mm)
Enclosure Material High Impact Polystyrene Composite
Family Zx/ZxA
Flying No
Frequency Response (-10 dB) 48 - 20000Hz (Full Range Mode)
Frequency Response (-3 dB) 60 - 20000Hz (Full Range Mode)
Grille Polyester Powder Coated, 18GA Galvanized Steel
Height 17.99" (457mm)
HF Transducer 1.25-inch DH2005
Input Connections XLR and TRS Combo; XLR with Independent Gain
LF Transducer 8-inch EV8L
Max. SPL/1m (calc) 126dB
Power Rating 800W
Power Requirement 120V: 95V - 132V, 50 - 60 Hz, 0.6A 230V:190V - 264V, 50 - 60 Hz, 0.4A
Powered or Passive Powered
Recommended High-Pass Frequency 36Hz (User Selectable)
Shipping Weight 22.49lbs (10.2kg)
Speaker Type Full-Range, powered monitors, powered speakers, two-way, wedges
Weatherized No
Weight Net 19lbs (8.62kg)
Width 11.1" (282mm)
Woofer Size 8inch
