Yamaha DXR10 MK3 10" Powered Loudspeaker
Yamaha DXR10 MK3 10" Powered Loudspeaker
SKU: SKU: SP-DXR10MK3-YAMAHA
Additional freight charges may apply to this item depending on your location. Please contact us on (03) 9364 9999 or email us for a freight quote. Alternatively, you may place your order and a member of our team will contact you if any additional shipping costs are required.
Low Stock – Call for Availability
Description
Description
The DXR10 mk3 is a 2-way, bi-amped, powered loudspeaker and is the most compact model in Yamaha’s DXR mk3 series, delivering exceptional clarity, precision, and a powerful 132 dB SPL output. Thanks to its compact, lightweight enclosure, it can function as a versatile utility speaker suitable for a wide variety of environments.
It features 10-inch LF and 1.75-inch HF proprietary high-durability speaker units, a large-diameter horn for directivity control across a wide frequency range, optimized port positioning to reduce standing wave effects, and a lightweight form-injection molded enclosure with a symmetrical, functional design.
A newly developed 2000W Class-D amplifier is combined with FIR-X™ tuning, Drive Motion Calibration™, application-specific DSP modes including FOH/MAIN and MONITOR with AUTO V/H POSITION, intelligent feedback suppression, Bluetooth® audio streaming, and remote control from iOS or Android devices using Yamaha’s D-Remote app.
The DXR10 mk3 also provides rigging points, dual-angle 35 mm pole sockets for 0° or -7° down tilt, and compatibility with the optional UB-DXRDHR10A U-bracket and SPCVR-DXR103 speaker cover.
Specification
Specification
| Speaker type | 2-way, Bi-amped Powered Speaker, Bass-reflex |
|---|---|
| Frequency range (-10dB) | 53 Hz - 20 kHz |
| Coverage area | H90° x V60° |
| Crossover | 1.8 kHz: FIR-X tuning™ (linear phase FIR filter) |
| Maximum Output Level | 132 dB SPL (Measured peak, IEC noise@1m) |
| LF | Diameter: 10" cone, Voice Coil: 2.5" |
| HF | Diaphragm: 1.75", Type: 1" throat compression driver |
| Amplifier | Class-D; 2000 W peak (LF 1700 W, HF 300 W); 1000 W RMS (LF 850 W, HF 150 W) |
| Signal processing | 32-bit / 96 kHz; FIR-X tuning™; Drive Motion Calibration™; FOH/MAIN, MONITOR, DJ, LIVE MUSIC, SPEECH, OFF; intelligent feedback suppressor |
| Analog input | 2 x Combo XLR/TRS |
| Analog output | OUTPUT1: XLR3-32 THRU; OUTPUT2: XLR3-32 THRU or DSP OUT |
| Bluetooth | Ver.5.0, A2DP (SBC, AAC), Class 1 |
| Remote control | D-Remote (iOS/Android app) |
| Cabinet material | Plastic (PP) |
| Finish | Black |
| Handle | Top x1 |
| Pole socket | Φ35 mm x2 (Bottom, 0° or -7°) |
| Rigging | Top x 2, Rear x 1 (Fit for M8 x 15 mm Eyebolts), Bottom x2, Side x 2 (Fit for M8 x 25 mm UB-DXRDHR10A) |
| Floor Monitor Angle | 55° |
| Dimensions | 310 mm (W) x 502 mm (H) x 310 mm (D) |
| Net weight | 14.5 kg (32.0 lbs) |
| Options | U-bracket: UB-DXRDHR10A, Cover: SPCVR-DXR103 |
