Midas DL151 24 Input Stage Box
Midas DL151 24 Input Stage Box
SKU: SKU: MIX-DL151-MIDAS
Regular price
$3,999.00
Regular price
$3,999.00
Sale price
$3,999.00
GST included.
Quantity
Low Stock – Call for Availability
Description
Description
Midas PRO SERIES DL151 is a 2U 19-inch fixed-configuration rack I/O unit with 24 mic/line level inputs and 24 Midas microphone preamplifiers. It supports remote operation over AES50 and selectable 96 kHz or 48 kHz operation for integration with Midas digital console systems.
- 24 mic/line inputs with Midas microphone preamplifiers
- 2.5 dB analogue gain steps
- Dual-redundant AES50 network connectivity
- Remote operation up to 100 m via CAT5/5e cable
- Selectable 96 kHz or 48 kHz sample rate operation
- Front-panel configuration and status display
Specification
Specification
| Inputs | 24 mic/line level inputs |
|---|---|
| Microphone Preamplifiers | 24 Midas microphone preamplifiers |
| Sample Rates | 96 kHz or 48 kHz |
| Network | AES50 |
| Remote Operation | Up to 100 m via CAT5/5e cable |
| Rack Size | 2U 19-inch |
| Dimensions | 483 x 376 x 88 mm |
| Weight | 6.9 kg |
| Power | 100 to 240 VAC, 50 to 60 Hz |
| Australis Vendor Item No. | 0606-ABO86-AU1 |
| UPC/EAN | 4033653014014 |
