EV ETX-15P 15" Two-Way Powered Loudspeaker
EV ETX-15P 15" Two-Way Powered Loudspeaker
SKU: SKU: ETX15P
Regular price
$2,990.00
Regular price
$4,175.00
Sale price
$2,990.00
Unit price
per
Taxes included.
Shipping calculated at checkout.
Low Stock
Description
Description
ETX-15P
15" TWO-WAY POWERED LOUDSPEAKER
- 15-inch LF SMX woofer
1.25-inch HF titanium compression driver
2000 W Class-D power amplifier with integrated FIR-Drive DSP
135 dB peak SPL
- 15-inch LF SMX woofer
- 1.25-inch HF titanium compression driver
- 2000 W Class-D power amplifier with integrated FIR-Drive DSP
- 135 dB peak SPL
Specification
Specification
| Connector Type | (2) XLR/TRS combo jack and (1) XLR link output |
| Coverage (Nominal -6 dB) H | 90 ° |
| Coverage (Nominal -6 dB) V | 60 ° |
SPECIFICATIONS |
|
| Crossover Frequency | 1500 Hz |
| Depth | 447 mm |
| Enclosure Material | 18-mm, 13-ply birch plywood with EVCoat |
| Family | ETX |
| Frequency Range | 40 Hz – 20 kHz |
| Frequency Response | 48 Hz – 20 kHz |
| Grill | 16AWG steel with powdercoat |
| Height | 691 mm |
| HF Transducer | DH3-B 1.25-in titanium compression driver |
| LF Transducer | SMX2150 380 mm (15 in) |
| Max. SPL/1m (calc) | 135 dB |
| Maximum SPL | 135 dB peak dB |
| Power Consumption | 100 – 240 V~, 50 – 60 Hz, 1.6 – 0.8 A |
| Power Rating | 2000 W |
| Powered or Passive | Powered |
| Shipping Weight | 31.5 kg |
| Speaker Type | Full-Range, two-way, powered speakers |
| Suspension | (8) M10 suspension points |
| Weight Net | 27.7 kg |
| Width | 431 mm |
| Woofer Size | 15 mm |
