SOUNDCRAFT UI24R REMOTE-CONTROLLED DIGITAL MIXER

Special Price A$2,379.00 Regular Price A$3,399.00

Availability: Available

Manufacturer

SOUNDCRAFT

SKU

UI24R

24-channel Digital Mixer/USB Multi-Track Recorder with Wireless Control

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

The Soundcraft Ui24R is a complete, rack-mountable, digital mixing and multi-track recording system that delivers flexible I/O, pristine sound quality, intuitive wireless control, and roadworthy reliability—all in a streamlined design. The system can double as a stagebox and can be controlled by up to 10 devices via Ethernet or built-in dual-band Wi-Fi, making it possible to control mixing and multi-track recording wirelessly from anywhere in the venue. Renowned Lexicon, dbx and DigiTech signal processing ensures pristine sound, while 20 Studer-designed microphone preamps deliver more professional inputs than any other mixer in its class. The compact, rack-mounted Ui24R is also compatible with the new HARMAN Connected PA system, and offers unprecedented control, versatility and power at an incredible value. From the stage to the studio, Soundcraft Ui24R is the ultimate system for artists, venues and engineers who need to save space and deliver superior sound.

FEATURES

HARMAN Sound Quality and ReliabilityUi24R brings together industry-leading HARMAN technologies to deliver unprecedented power and mission-critical stability. Renowned Studer preamps deliver rich sound for live performance and multi-track recording, while iconic Lexicon reverbs, choruses, delays, and dbx compression offer polished results for vocals, acoustic guitar and more. dbx AFS2 automatic feedback suppression is available on all monitor outputs, providing an excellent live experience. Plus, DigiTech guitar amp modeling brings a host of effects to any performance, particularly when low stage volume is desired.
More Ways to Connect
When you need a mixer with comprehensive connections and a compact footprint, Ui24R provides the perfect, streamlined solution. The Ui24R allows you to mix from multiple sources including 10 combo 1/4"-TRS/XLR, 10 XLR, 2 line level inputs, and 2 channels of digital USB playback for a total of 24 channels. With its flexible and high-quality I/O, Ui24R gives venues, bands and engineers room to grow, with expanded creative options.
More Ways to ControlControl Ui24R from the device of your choice (tablet, phone, PC, Mac) via iOS, Android, Windows, Mac OS and Linux browsers, without installing apps. Onboard dual-band WiFi ensures you (and up to 9 members of the band) can always stay in control without relying on an independent router or the venue’s WiFi. Musicians can adjust their individual mix on stage while the FOH engineer optimizes the audience experience.
Multi-track Recording and PlaybackUi24R is more than just a complete mixing system—it’s also a top-notch recording tool. Enjoy peace of mind with dual-path, multi-track recording of all 22 inputs and your stereo mix, directly to a USB storage drive AND a connected computer. The multi-channel USB audio interface also makes it easy to integrate the Ui24R into your recording studio for production work with your favorite DAW.
More FreedomTraditional mixers offer lots of functionality, but can only be controlled from the mix console position. The Ui24R surfaceless mixer combines the power and versatility of a large-format console with a compact design and complete Wi-Fi control. With Ui24R, you can finally have the features you need, plus the freedom to control your mixer from anywhere in the venue.
Compatible with HARMAN Connected PAThe Ui24R mixer’s embedded ioSYS technology enables easier setup and control when used with the HARMAN Connected PA app and compatible products. Connected PA delivers seamless plug-and-play operation with a variety of HARMAN equipment and enables you to control your entire live sound system with one app. Products within the Connected PA system self-identify and retain presets for effortless setup, and setup wizards help you quickly optimize volume, configuration settings and sound quality. Current products with embedded ioSYS technology and HARMAN Connected PA compatibility include JBL PRX800W loudspeakers, dbx Di1 direct boxes, and AKG P5i microphones.

More Information

Specification

Type	Digital Remote-controlled Mixer
Channels	24
Inputs - Mic Preamps	10 x XLR-1/4" combo, 10 x XLR
Phantom Power	Yes
Inputs - Line	1 x stereo RCA
Outputs - Main	2 x XLR, 2 x 1/4"
Busses/Groups	8 x XLR (aux outs)
Data I/O	2 x Ethernet, 1 x HDMI
USB	4 x Type A, 1 x Type B
Headphones	2 x 1/4"
EQ Bands	4-band parametric EQ, 31-band graphic EQ
Effects	Lexicon Reverb, Lexicon Delay, DigitTech guitar amp modeling
Signal Processing	dbx compression, dbx AFS2 auto feedback suppression, noise gate, de-esser
Features	Built-in dual-band Wi-Fi, real time frequency analyzer, 24 track recording to USB
Software	Remote control with iOS, Android, Windows, OS X and Linux
Rackmountable	Yes (4U)
Depth	6.8"
Width	19"
Weight	10kg.
Manufacturer Part Number	5076585

Manufacturer

SOUNDCRAFT

Package

1 Pack

Specification

Type	Digital Remote-controlled Mixer
Channels	24
Inputs - Mic Preamps	10 x XLR-1/4" combo, 10 x XLR
Phantom Power	Yes
Inputs - Line	1 x stereo RCA
Outputs - Main	2 x XLR, 2 x 1/4"
Busses/Groups	8 x XLR (aux outs)
Data I/O	2 x Ethernet, 1 x HDMI
USB	4 x Type A, 1 x Type B
Headphones	2 x 1/4"
EQ Bands	4-band parametric EQ, 31-band graphic EQ
Effects	Lexicon Reverb, Lexicon Delay, DigitTech guitar amp modeling
Signal Processing	dbx compression, dbx AFS2 auto feedback suppression, noise gate, de-esser
Features	Built-in dual-band Wi-Fi, real time frequency analyzer, 24 track recording to USB
Software	Remote control with iOS, Android, Windows, OS X and Linux
Rackmountable	Yes (4U)
Depth	6.8"
Width	19"
Weight	10kg.
Manufacturer Part Number	5076585
