EV ZLX-8 G2 12" TWO-WAY PASSIVE LOUDSPEAKER
Special Price
A$699.00
Regular Price
A$935.00
ORDER IN
SKU
ZLX8-G2 Passive
1000W
- The next generation of the world’s #1 pro-audio loudspeaker – With more than a million units delivered, satisfied users and venues worldwide positioned the original ZLX series as the industry standard for providing real professional performance at an accessible price point.
- Stepping up – ZLX G2 builds on its predecessor’s winning formula with increased output, frequency range and durability.
- Perfect for a wide range of installations and applications – in addition to portable sound for live performances and events, compact size with big performance and a range of user-friendly mounting options make ZLX G2 a great fit for installation in bars, restaurants, clubs, houses of worship, and many more applications
ZLX G2 is the second generation of the phenomenally successful ZLX series of portable loudspeakers. Building on the best of what made the original ZLX series an industry icon, the ZLX G2 lineup offers a range of next-level features and functionality and includes 8” (new for the series), 12” and 15” two-way models in both powered and passive versions.
- ZLX-G2 is the next generation of the bestselling pro-audio loudspeaker series from Electro-Voice
- Increased maximum SPL output and extended frequency response
- Robust and ergonomic design for day-to-day durability and portability
- Recommended to use with Dynacord DSP power amplifiers
- SONICUE integration - optimized speaker settings for best performance
| Custom Stock Status | ORDER IN | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Specification |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Manufacturer | EV |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Package | 1 Pack |
| Specification | ZLX-8-G2 | ZLX-12-G2 | ZLX-15-G2 |
|---|---|---|---|
| Frequency response (-3 dB) (Hz) | 67 Hz – 20,000 Hz | 69 Hz – 18,500 Hz | 68 Hz – 18,000 Hz |
| Frequency range (-10 dB) (Hz) | 55 Hz – 20,000 Hz | 55 Hz – 20,000 Hz | 53 Hz – 20,000 Hz |
| Axial sensitivity (dB SPL 1W/1m) | 90 dB SPL 1W/1m | 93 dB SPL 1W/1m | 95 dB SPL 1W/1m |
| Maximum sound pressure level at a distance of 1 m (dB) | 124 dB | 125 dB | 126 dB |
| High pass frequency (Hz) | 60 Hz | 48 Hz | 40 Hz |
| Crossover frequency (kHz) | 2 kHz | 2 kHz | 2 kHz |
| Coverage angle HxV (°) | 90° x 60° | 90° x 60° | 90° x 60° |
| Power handling (continuous) (W) | 250 W | 250 W | 250 W |
| Power handling (peak) (W) | 1,000 W | 1,000 W | 1,000 W |
| Nominal impedance (Ω) | 8 Ω | 8 Ω | 8 Ω |
| LF transducer | WECA2088 | WECA2128 | WECA2158 |
| LF transducer size (in) | 8 in | 12 in | 15 in |
| LF transducer magnet material | Ferrite | Ferrite | Ferrite |
| HF transducer | DH-1K | DH-1K | DH-1K |
| HF transducer type | Compression driver | Compression driver | Compression driver |
| HF transducer size (in) | 1.4 in | 1.4 in | 1.4 in |
| HF transducer diaphragm material | Titanium | Titanium | Titanium |
| Dimensions (H x W x D) (mm) | 459.6 mm x 289.9 mm x 280.5 mm | 621.1 mm x 356.2 mm x 356 mm | 697.6 mm x 422.8 mm x 383.1 mm |
| Dimensions (H x W x D) (in) | 18.09 in x 11.41 in x 11.04 in | 24.45 in x 14.02 in x 14.01 in | 27.46 in x 16.65 in x 15.08 in |
| Shipping dimensions (H x W x D) (mm) | 500 mm x 390 mm x 350 mm | 670 mm x 420 mm x 405 mm | 765 mm x 490 mm x 490 mm |
| Shipping dimensions (H x W x D) (in) | 19.69 in x 15.35 in x 13.78 in | 26.38 in x 16.54 in x 15.94 in | 30.12 in x 19.29 in x 19.29 in |
| Weight (kg) | 10.15 kg | 14.26 kg | 16.44 kg |
| Weight (lb) | 22.38 lb | 31.44 lb | 36.24 lb |
| Shipping weight (kg) | 11.92 kg | 16.26 kg | 19.18 kg |
| Shipping weight (lb) | 26.28 lb | 35.85 lb | 42.28 lb |
